VANSE WS-980 High Efficiency Av Ground Tool Cua-txias 4 Stroke Vibratory Pem Teb Paving Qhob Laser Screed Leveling Tshuab

VANSE WS-980 High Efficiency Av Ground Tool Cua-txias 4 Stroke Vibratory Pem Teb Paving Qhob Laser Screed Leveling Tshuab

WS-980-1

WS-980-2

WS-980- (3)

WS-980- (4)

WS-980- (5)

VANSE WS-980 High Efficiency Av Ground Tool Cua-txias 4 Stroke Vibratory Pem Teb Paving Qhob Laser Screed Leveling Tshuab

WS-980-_01

VANSE WS-980 High Efficiency Av Ground Tool Cua-txias 4 Stroke Vibratory Pem Teb Paving Qhob Laser Screed Leveling Tshuab

Lub npe	Qhob Laser Screed
Hom	WS-980
Hom cav	Briggs & Stratton 38E3
Yam ntxwv	Roj av, Cua Txias 4 Stroke, 2 Lub tog raj kheej
Hwj chim	23 kWm
Roj tank ntim	20L
Lubrication roj	1.7L
Screed dav	3.0M
Paving hom	Hydraulic Ntsia Hlau Conveyor Paving
Paving thickness	5-30CM
Vibrating system	Hydraulic Vibration Tsav
Excitation quab yuam	3000N
Kev vibration zaus	70hz ua
Kev teeb tsa	Laser Emitter, Laser txais, Tripod
Laser Tswj	Microcomputer Laser Scanning tshuab
Muaj feem xyuam	Flat nto, Slope, Ob chav nqes hav (peb-dimensional)
Tsav hom	Tag nrho hydraulic tsav,
Lub log	Khoom puncture-pov thawj thiab antiskid
Lub log dav	9 cm & 20 cm
WS-980 configured 2 khub log tsheb(9cmX2, 20cmX2)
Log khiav	12 40mm
Log puag	13 40mm
Taug kev ceev	0-4.5 km/h
Tswj ceev	Stepless Ceev Hloov.
Tig	Hydraulic Tsav, kauj log tswj.
Hwj chim	Sab nraud lub cev muaj zog
Theoretical ntws	20m³/h
Rated siab	7 kgs/qw
Daim ntawv dimension	3300 * 3470 * 1650 hli
Net nyhav	10 20 Kg

VANSE WS-980 High Efficiency Av Ground Tool Cua-txias 4 Stroke Vibratory Pem Teb Paving Qhob Laser Screed Leveling Tshuab

vs836-4-3_05

vs836-4-3_06

vs836-4-3_07

vs836-4-3_08

vs836-4-3_10

vs836-4-3_11
